MAINTENANCE AND FEATURES:
Quartz sand filter uses one or several filter media, operates at room temperature, acid and alkali,
oxidation, the PH scope is from 2 to13. Perfect protection device and monitoring
instrumentation has a backwash function, dirt and other pollutants are quickly washed away, and
water consumption function, can be set to automatic functions according to users’ requirements.
Under certain pressure, the liquid goes through the touch flocculation of the media , to adsorpt,
retent, remove the impurities, so as to achieve the purpose of filtering. Its interior packing is
generally as follows: quartz sand, anthracite, granular porous ceramics, manganese sand, the user
Its filter precision is between 0.005 and 0.01m, which can effectively remove colloid particles and
organic polymer.
Mainly used to remove suspended solids in water. The device in conjunction with other water
treatment equipment, widely used in water purification, circulating water in the purification of
sewage treatment and other types of water treatment works.
Quartz sand filter technical parameters: 1, operating parameters, 2.water quality parameters
The design filtration rate: 8 - 10 m / h, final head loss: 1.7 m, water turbidity
: less than 15 degrees, effluent turbidity : less than 3 degrees.
Anti-cleaning strength :4-15 l / sec square meters, and water turbidity is less than 10 degrees,
effluent turbidity is less than 2 degrees
Wash lasted 5 to 7 minutes, Media: quartz sand, water pressure ≥0.15Mpa
Cushion thickness 200 - 400 mm, filter depth: 800 mm, water pressure: ≥ 0.04Mpa ,anti-flushing
water pressure: ≥ 0.15Mpa
Peep mouth, water cap, quartz sand, pressure gauges, valves, all pipeline
|
